| Engine Specification | ALMW04D |
|---|---|
| No: of cylinder & configuration | 4, In-line |
| Rated Power in KW | 41 Kw @ 2000 RPM 66 Kw @ 2800 RPM |
| Rated power in PS | 56Ps @ 2000 RPM 88 Ps @ 2800 RPM |
| Displacement | 4 Litres |
| Bore X Stroke | 104 mm X 118 mm |
| Flywheel housing & flywheel | SAE 3 & 11.5 |
| Max torque | 250 Nm @ 1800 RPM |
| Aspiration | Naturally aspirated |
| Fuel injection pump | Mechanical, In-line pump |
| Cooling system | Sea water cooled heat exchanger |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 10Litres |
| Lubricating oil capacity | 8.5 Litres |
| Starting system | Electric starting - 12V Dc |
| Charging Alternator Capacity | 12V @ 36Amps |
| Engine dry weight without gearbox | 380 kg |
| Marine Engine size with GB,PTO (L X B X H) | 1289mm X 812mm X 1196mm |
| Engine Specification | ALM4CTI |
|---|---|
| No: of cylinder & configuration | 4, In-line |
| Rated Power in KW | 90Kw @ 2400 RPM |
| Rated power in PS | 120 Ps @ 2400 RPM |
| Displacement | 3.84 Litres |
| Bore X Stroke | 104 mm X 113 mm |
| Flywheel housing & flywheel | SAE 3 & 11.5 |
| Max torque | 410 Nm @ 1400 RPM |
| Aspiration | Turbo charged & Intercooled |
| Fuel injection pump | Mechanical Inline Pump |
| Cooling system | Sea water cooled heat exchanger & charged air cooler |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 10Litres |
| Lubricating oil capacity | 11 Litres |
| Starting system | Electric starting - 24V Dc |
| Charging Alternator Capacity | 24V @ 55Amps |
| Engine dry weight without gearbox | 660 Kg |
| Marine Engine size with GB,PTO (L X B X H) | 1816mm X 1040mm X 1587mm |
| Engine Specification | ALM6ETI |
|---|---|
| No: of cylinder & configuration | 6, In-line |
| Rated Power in KW | 111Kw @ 2000 RPM 120Kw @ 2400RPM |
| Rated power in PS | 151 Ps @ 2000 RPM 160 Ps @ 2400 RPM |
| Displacement | 5.7 Litres |
| Bore X Stroke | 104mm X 113 mm |
| Flywheel housing & flywheel | SAE 2 & 11.5 |
| Max torque | 550 Nm @ 1600 RPM |
| Aspiration | Turbo Charged & Inter Cooled |
| Fuel injection pump | Mechanical Inline Pump |
| Cooling system | Sea water cooled heat exchanger & charged air cooler |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 24Litres |
| Lubricating oil capacity | 16 Litres |
| Starting system | Electric starting - 24V Dc |
| Charging Alternator Capacity | 24V @ 55Amps |
| Engine dry weight without gearbox | 795 Kg |
| Marine Engine size with GB,PTO (L X B X H) | 2277mm X 1056mm X 1367mm |
| Engine Specification | ALM6ETI-MK1 |
|---|---|
| No: of cylinder & configuration | 6, In-line |
| Rated Power in KW | 127Kw @ 2000 RPM 135Kw @ 2400 RPM |
| Rated power in PS | 172 Ps @ 2000 RPM 180 Ps @ 2400 RPM |
| Displacement | 5.7 Litres |
| Bore X Stroke | 104mm X 113 mm |
| Flywheel housing & flywheel | SAE 2 & 11.5 |
| Max torque | 660 Nm @ 1600 RPM |
| Aspiration | Turbocharged & Intercooled |
| Fuel injection pump | Mechanical Inline Pump |
| Cooling system | Sea water cooled heat exchanger & charged air cooler |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 24Litres |
| Lubricating oil capacity | 16 Litres |
| Starting system | Electric starting - 24V Dc |
| Charging Alternator Capacity | 24V @ 55Amps |
| Engine dry weight without gearbox | 795 Kg |
| Marine Engine size with GB,PTO (L X B X H) | 2277mm X 1056mm X 1367mm |
| Engine Specification | ALM6DTI |
|---|---|
| No: of cylinder & configuration | 6, In-line |
| Rated Power in KW | 140Kw @ 2000 RPM 153Kw @ 2500 RPM |
| Rated power in PS | 190 Ps @ 2000 RPM 205 Ps @ 2500 RPM |
| Displacement | 5.7 Litres |
| Bore X Stroke | 104mm X 113 mm |
| Flywheel housing & flywheel | SAE 2 & 11.5 |
| Max torque | 750 Nm @ 1500 RPM |
| Aspiration | Turbocharged & Intercooled |
| Fuel injection pump | Mechanical Inline Pump |
| Cooling system | Sea water cooled heat exchanger & charged air cooler |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 24Litres |
| Lubricating oil capacity | 16 Litres |
| Starting system | Electric starting - 24V Dc |
| Charging Alternator Capacity | 24V @ 55Amps |
| Engine dry weight without gearbox | 835 Kg |
| Marine Engine size with GB,PTO (L X B X H) | 2277mm X 1056mm X 1367mm |
| Engine Specification | ALM6DTI MK1 |
|---|---|
| No: of cylinder & configuration | 6, In-line |
| Rated Power in KW | 155Kw @ 2000 RPM 161Kw @ 2400 RPM |
| Rated power in PS | 207 Ps @ 2000 RPM 220 Ps @ 2400 RPM |
| Displacement | 5.7 Litres |
| Bore X Stroke | 104mm X 113 mm |
| Flywheel housing & flywheel | SAE 2 & 11.5 |
| Max torque | 820 Nm @ 1600 RPM |
| Aspiration | Turbocharged & Intercooled |
| Fuel injection pump | Mechanical Inline Pump |
| Cooling system | Sea water cooled heat exchanger & charged air cooler |
| Coolant type/ratio | Gulf Euro cool LL Max / 50:50 |
| Coolant capacity | 24 Litres |
| Lubricating oil capacity | 16 Litres |
| Starting system | Electric starting - 24V Dc |
| Charging Alternator Capacity | 24V @ 55Amps |
| Engine dry weight without gearbox | 835 Kg |
